The FAC Series from FS-Curtis comprises a range of heavy duty, portable diesel air compressors offering superior efficiency, quality and reliability in an environmentally responsible manner. There is a wide selection of models including box and trailer type configurations with continuous duty outputs from
1.84 to 34 m3/min (65 to 1,200 cfm) and rated pressures from 7 to 24.5 bar (100 to 355 psi). A factory installed aftercooler option is available for most of the 7 bar compressors.
|
Free Air Delivery |
7.5 m³/min (265 cfm) |
|
Rated Pressure |
6.9 bar (100 psi) |
|
Maximum Pressure |
9 bar (130 psi) |
|
Aftercooler |
Air-to-Air |
|
Engine |
Yanmar 4TNV98T-NHK |
|
Fuel Consumption |
15 L/h @ 100% Load |
|
Noise Level @ 7 m |
69 dB(A) |
|
Weight (Wet) |
1,290 kg |
|
Product Code |
FS FAC-75B |
